# Core Animation Layers forming a 3D cube

Making a 3D cube with Core Animation layers

I’ve been researching `Core Animation` framework for the past few months.
I’ve started with several books on the subject, but I found watching related WWDC videos most rewarding. The presenters put the content in a relevant context which makes it easier to apprehend and learn from it.

## 1. Introduction

One WWDC session particularly intrigued me: “2011–421 Core Animation Essentials”. They presented their demo named: “Layers in Perspective”, and it showed six layers, forming a flattened cube:

The sixth layer is hiding behind the layer number 5. It has a lower `zPosition` then the layer above it.

They have also demonstrated opening and closing the cube formation.

So, I have decided to demonstrate that.

Here’s a link to a GitHub repo with the source code:
Core Animation 3D Cube

Here’s the animation:

You can also see it on You Tube

Layers in `Core Animation` live in `3D` geometry. But a layer is a `2D` construct, so `Core Animation` coordinate space is called a `2.5D` geometry.

To illustrate that just see what happens when you mess up your transformations.

Layers are `2D` objects, they don’t understand the third dimension.
They are like playing cards in space., and there is no `depth buffer` available.

And also, intersecting layers should be avoided because in the image above, Core Animation needs to do a lot of work.

So just to draw the `red` layer intersecting only the `blue` layer, Core Animation needs to

• cut the `red` layer into two pieces
• render back part of the `red` layer
• then render the full `blue` layer
• then render the front part of the `red` layer again

And all that work is for just intersection, and here we have multiple.

## 2. Building the Cube in 3D

### 2.1. Setting up the multi-platform project

I wanted the project to fun on the `macOS` , `iOS` and `iPadOS`, so I used AllApples Swift package.

After removing the storyboards and pimping up the `AppDelegate` and `main.swift` for the `macOS` version, and `SceneDelegate` for the mobile versions, I was ready to start.

#### 2.1.1. `main.swift` for the macOS

``````import Cocoa
let delegate = AppDelegate()
NSApplication.shared.delegate = delegate
_ = NSApplicationMain(CommandLine.argc, CommandLine.unsafeArgv)
``````

#### 2.1.2. AppDelegate for the `macOS`

``````import Cocoa
import AllApples

class AppDelegate: NSObject, NSApplicationDelegate {
private var window: NSWindow?
window = AppSceneDelegate.makeWindow_Mac(theVC: CommonViewController())
}
}
``````

#### 2.1.3. SceneDelegate for the `iOS` and `iPadOS`

``````import UIKit
import AllApples

class SceneDelegate: UIResponder, UIWindowSceneDelegate {
var window: UIWindow?
func scene(_ scene: UIScene, willConnectTo session: UISceneSession, options connectionOptions: UIScene.ConnectionOptions) {
guard let aScene = (scene as? UIWindowScene) else { return }
window = AppSceneDelegate.makeWindow_iOS(theScene: aScene, theVC: CommonViewController())
}
}
``````

### 2.2. Building the Basic Blocks

The first I did is make a `PlainLayerView `.

It is an `AView` descendant, which means that it is `typedef-ed` to be either a `UIView` or a `NSView`.

It is an intermediary object just to set up a thing on the `macOS` as well (doesn’t work yet).

I then created `CustomLayerView` to have nice sides for the cube, with `CATextLayer` as the number of the cube side, and a nice rounded border, so that we can peek into our cube while rotating.

Here’s the image of all six layers drawn by using a `CustomLayerView`

This layout was abandoned because I couldn’t make the transformation of `purple` view to work when transforming in `3D`.

The solution is to add an additional `CATransformLayer` to the `green` layer, and mount the `purple` layer onto it. As explained in this blog post by Oliver Drobnik Cubed CoreAnimation Conundrum.

But I didn’t want to lose the linearity of the solution, and I used the approach demonstrated in the mentioned WWDC session: “2011–421 Core Animation Essentials”

They used the `zOrder` property of a layer, and so I put `purple` layer on top of the `red` layer to achieve that.

``````    if number == 4 {
view.layer.zPosition = 1
}
``````

As you can see in the image below, the `purple` layer is in front of the `red` layer, which is obvious when we rotate the flattened cube.

### 2.3. Turning the Transform On and Off

I did take the approach that Over Drobnik did in his article: Cubed CoreAnimation Conundrum , and used it like this:

``````	side4.layer?.zPosition = on ? CACube3DView.sideWidth : 1
side1.layer?.transform = on ? CATransform3D.transformFor3DCubeSide(1, zWidth: CACube3DView.sideWidth)  : CATransform3DIdentity
side2.layer?.transform = on ? CATransform3D.transformFor3DCubeSide(2, zWidth: CACube3DView.sideWidth)  : CATransform3DIdentity
side3.layer?.transform = on ? CATransform3D.transformFor3DCubeSide(3, zWidth: CACube3DView.sideWidth)  : CATransform3DIdentity
side4.layer?.transform = on ? CATransform3D.transformFor3DCubeSide(4, zWidth: CACube3DView.sideWidth)  : CATransform3DIdentity
side5.layer?.transform = on ? CATransform3D.transformFor3DCubeSide(5, zWidth: CACube3DView.sideWidth)  : CATransform3DIdentity
side6.layer?.transform = on ? CATransform3D.transformFor3DCubeSide(6, zWidth: CACube3DView.sideWidth)  : CATransform3DIdentity
``````

### 2.4. Transforming the Layers to Form a Cube

I didn’t use his transform code, since he used that additional `CATransformLayer`, so it wouldn’t work. So, here’s a small extension on the `CATransform3D`

``````public extension CATransform3D {
static func transformFor3DCubeSide(_ number: Int, zWidth: CGFloat) -> CATransform3D {

let halfPi = CGFloat(Double.pi) / 2.0
var trans = CATransform3DIdentity
switch number {
case 1:
trans = CATransform3DMakeRotation(halfPi, 0, 1, 0)
break
case 2:
trans = CATransform3DIdentity
break
case 3:
trans = CATransform3DMakeRotation(-halfPi, 0, 1, 0)
break
case 4:
trans = CATransform3DMakeTranslation(0, 0, zWidth)
break
case 5:
trans = CATransform3DMakeRotation(-halfPi, 1, 0, 0)
break
case 6:
trans = CATransform3DMakeRotation(halfPi, 1, 0, 0)
break
default:
break
}
return trans
}
}
``````

I actually used the approach form that WWDC session, and also used `anchorPoint` properties of the `CALayer`.

### 2.5. Positioning Cube Sides

Here’s a little extension on `CGPoint` that returns a tuple of our cube side positions and anchor points:

``````public extension CGPoint {
static func anchorPointAndPositionForCubeSideLayer(number: Int, sideSize: CGFloat) -> (anchorPoint: CGPoint, position: CGPoint) {
var resultAnchorPoint = CGPoint(x:0.5, y:0.5)
var resultPosition = CGPoint(x:0.0, y:0.0)
let halfSideSize: CGFloat = sideSize / 2.0
switch number {
case 1:
resultAnchorPoint = CGPoint(x:1.0, y:0.5)
resultPosition = CGPoint(x:-halfSideSize, y:0.0)
break
case 2:
resultAnchorPoint = CGPoint(x:0.5, y:0.5)
resultPosition = CGPoint(x:0.0, y:0.0)
break
case 3:
resultAnchorPoint = CGPoint(x:0.0, y:0.5)
resultPosition = CGPoint(x:halfSideSize, y:0.0)
break
case 4:
resultAnchorPoint = CGPoint(x:0.5, y:0.5)
resultPosition = CGPoint(x:0.0, y:0.0)
break
case 5:
resultAnchorPoint = CGPoint(x:0.5, y:1.0)
resultPosition = CGPoint(x:0.0, y:-halfSideSize)
break
case 6:
resultAnchorPoint = CGPoint(x:0.5, y:0.0)
resultPosition = CGPoint(x:0.0, y:halfSideSize)
break
default:
break
}
return (anchorPoint: resultAnchorPoint, position: resultPosition)
}
}
``````

In the image below I have marked where the `anchor points` are for each layer:

The only fallacy in the image above, is that the `purple` layer is actually above our `red layer`, but I wanted to show where those anchor points are.
So, the actual image looks like this, but we now don’t see the `red` layer.

An Anchor point is a center of rotation. It determines how will the layer rotate.
Imagine holding a playing card with two fingers. Then try to spin the card. The anchor point of that card is where you are holding it with fingers.

## 3. Responding to Gestures

I made a small `GestureRecognizerView` to be able to respond to gestures and move, rotate and scale our layers.

It hooks-up:

• `NSPanGestureRecognizer` and `UIPanGestureRecognizer`
• `func rotate(with event: NSEvent)` and `UIRotationGestureRecognizer`
• `NSClickGestureRecognizer` and `UITapGestureRecognizer`
• `func magnify(with event: NSEvent)` and `UIPinchGestureRecognizer`

It then exposes all those events to the developer to use:

``````public extension GestureRecognizerView {
@objc func rotationChanged(degrees: Float) {}
@objc func rotationChanged(radians: Float) {}
@objc func displacementChanged(displacement: CGPoint) {}
@objc func scaleChanged(scale: CGFloat) {}
@objc func tapHappened() {}
}
``````

## 4. Building a Layer to hold a Cube

`CACube3DView` will hold the six layers than (can) make a cube.

In order for `Core Animation` to render the transformed views in perspective, there is a property `sublayerTransform`.

You either use that property of your parent layer, or aaa another layer class to your layer hierarchy: `CATransformLayer`. I opted to use that.

``````private(set) public lazy var transformedLayer: CALayer = {
let l = CATransformLayer()
l.name = "Transform Layer"
#if os(OSX)
l.isGeometryFlipped = true
#endif
return l
}()
``````

When adding sublayers, I add them to this `transformedLayer` property, and not my view’s layer.

``````func addSideSubview(_ subview: AView) {

#if os(iOS) || os(tvOS)
#endif

#if os(OSX)
if let aLayer = subview.layer {
} else {
fatalError("`subview.layer` == `nil`")
}
#endif
}
``````

## 5. Perspective & Rotation

When the app first runs it shows in perspective.
I made a little extension:

``````public extension CATransform3D {
static func somePerspectiveTransform() -> CATransform3D {
var perspective = CATransform3DIdentity;
perspective.m34 = -1.0 / 500.0;
perspective = CATransform3DRotate(perspective, CGFloat(Double.pi) / 8, 1, 0, 0);
perspective = CATransform3DRotate(perspective, CGFloat(Double.pi) / 8, 0, 1, 0);
perspective = CATransform3DScale(perspective, 0.7, 0.7, 0.7)
return perspective
}
}
``````

The part: `perspective.m34 = -1.0 / 500.0;` sets the perspective.

The `.34` field of a matrix shows the amount of perspective distortion applied.

The amount `500` is often used in examples. If it were smaller, the layers would seem very close and distorted, like a fish-eye effect.

This is the initial transform, but we want to be able to move and rotate our cube (flattened or not) with our fingers.

Here’s the code:

``````public extension CATransform3D {

func rotationFromDisplacement(_ displacement: CGPoint, sideWidth: CGFloat, is3D: Bool) -> CATransform3D {

var currentTransform = self

let totalRotation: CGFloat = sqrt(displacement.x * displacement.x + displacement.y * displacement.y)
let angle: CGFloat = totalRotation * .pi / 180.0

let xRotationFactor = displacement.x / angle
let yRotationFactor = displacement.y / angle

if is3D {
currentTransform = CATransform3DTranslate(currentTransform, 0, 0, sideWidth / 2.0)
}

var rotationalTransform = CATransform3DRotate(currentTransform, angle,
(xRotationFactor * currentTransform.m12 - yRotationFactor * currentTransform.m11),
(xRotationFactor * currentTransform.m22 - yRotationFactor * currentTransform.m21),
(xRotationFactor * currentTransform.m32 - yRotationFactor * currentTransform.m31))

if (is3D) {
rotationalTransform = CATransform3DTranslate(rotationalTransform, 0, 0, -sideWidth / 2.0);
}

return rotationalTransform
}
}
``````

We call it from our pan-gesture methods

``````  override func displacementChanged(displacement: CGPoint) {
guard !(displacement.x == 0 && displacement.y == 0) else { return }

let rotationTransform = transformedLayer.sublayerTransform.rotationFromDisplacement(displacement, sideWidth: CACube3DView.sideWidth, is3D: isOn)
transformedLayer.sublayerTransform = rotationTransform
}
``````

We hooked up the pan-gestures prior:

``````#if os(OSX)
private func setupPanGestureRecognizer() {
let panGR = NSPanGestureRecognizer(target: self, action: #selector(handlePanGesture(_:)))
}
@objc func handlePanGesture(_ gestureRecognizer: NSPanGestureRecognizer) {
let displacement: CGPoint = gestureRecognizer.translation(in: self)
handlePan(displacement: displacement, changed: gestureRecognizer.state == .changed)
}
#endif

#if os(iOS) || os(tvOS)
private func setupPanGestureRecognizer() {
let panGR = UIPanGestureRecognizer(target: self, action: #selector(handlePanGesture(_:)))
}

@objc func handlePanGesture(_ gestureRecognizer: UIPanGestureRecognizer) {
let displacement: CGPoint = gestureRecognizer.translation(in: self)

handlePan(displacement: displacement, changed: gestureRecognizer.state == .changed)

if gestureRecognizer.state == .changed {
gestureRecognizer.setTranslation(.zero, in: self)
}
}
#endif
``````

We can also add a simple rotation transform for the rotation events/ gestures.

``````  override func rotationChanged(radians: Float) {
let transform = transformedLayer.sublayerTransform
let rot = CATransform3DRotate(transform, CGFloat(radians), 0, 1, 0)
transformedLayer.sublayerTransform = rot
}
``````

And scale, in all three axes:

``````  override func scaleChanged(scale: CGFloat) {
let scaleTransform = CATransform3DScale(transformedLayer.sublayerTransform, scale, scale, scale)
transformedLayer.sublayerTransform = scaleTransform
}
``````

The `tap` turns on and off our 3D transform

``````  override func tapHappened() {
set3DCube(on: isOn)
}
``````

Here’s the 3D cube code

``````  func set3DCube(on: Bool) {
side4.layer.zPosition = on ? CACube3DView.sideWidth : 1
side1.layer.transform = on ? CATransform3D.transformFor3DCubeSide(1, zWidth: CACube3DView.sideWidth) : CATransform3DIdentity
side2.layer.transform = on ? CATransform3D.transformFor3DCubeSide(2, zWidth: CACube3DView.sideWidth) : CATransform3DIdentity
side3.layer.transform = on ? CATransform3D.transformFor3DCubeSide(3, zWidth: CACube3DView.sideWidth) : CATransform3DIdentity
side4.layer.transform = on ? CATransform3D.transformFor3DCubeSide(4, zWidth: CACube3DView.sideWidth) : CATransform3DIdentity
side5.layer.transform = on ? CATransform3D.transformFor3DCubeSide(5, zWidth: CACube3DView.sideWidth) : CATransform3DIdentity
side6.layer.transform = on ? CATransform3D.transformFor3DCubeSide(6, zWidth: CACube3DView.sideWidth) : CATransform3DIdentity
}
``````

We either set the `identity transform`, which means `no transform`, to our cube sides, or the transform appropriate for that particular side.

## 6. macOS Troubles

I suppose I need to do further investigation in how `macOS` treats layers of `NSView`, for this little experiment is not working on the `macOS`, yet.
Here’s how the flattened cube looks on the `macOS`

So, the positioning of the layers is not respected.

And here is the cube in 3D:

I did try to force the `isGeometryFlipped = true` everywhere. Anyway this needs more work.

If you want to help with the `macOS` implementation, please, be my guest.

Here’s a link to a GitHub repo with the source code:
Core Animation 3D Cube
